B11ZT Low pressure solenoid valve

Application

B11Z micro solenoid valve is widely used in petrochemical, electrical,mechanical, medical, scientific research, filling, building, combustionengine, pipeline medium automatic control and other fields.

Features

Small size; Exquisite type; Zero pressure start, quick switch andgood sealing. Autocratic coil, not easy to destroy; It is suitable forsmall caliber and low pressure pipeline system.

Principle

It is a kind of direct pulling principle. When there is no pressure .difference between the inlet and outlet, the electromagnetic forcelifts the movable valve core directly upward after power is applied, .the valve port opens and the medium passes through. After thepower is cut off, the moving valve core closes the valve portdownward under the action of spring force and medium pressureto cut off the fluid medium.
